Mobile Batching Plant




  • What is it?

    The Mobile Batching Plant is a mobile cement batching system designed for large works requiring on site manufacturing of concrete.

    It’s the ideal solution for rural and remote concreting.

  • How does it work?

    The Mobile Batching Plant is fed stone, sand, and cement via a loader. The material is then transferred into an agitator via the plant’s belt elevator. Water is added at the end of the elevator. After mixing by the agitator, the concrete is then ready to pour in the usual manner.

    The Mobile Batching Plant doesn’t make concrete; it prepares it.

  • Who is it for?

    • large businesses that require on-site concrete manufacturing

    • businesses located remotely without easy and affordable access to manufactured concrete

    • concrete businesses with large service areas

  • Benefits

    The Mobile Batching Plant has the capacity to manufacture concrete quickly and easily on site.

    The Mobile Batching Plant has a large capacity hopper and a high output elevator. All you need is a front-end loader, concrete ingredients, and an agitator for the mixing of the concrete.

    Another benefit of the Mobile Batching Plant is that it’s light and easily transportable.

    On farm, a bonus of the Mobile Batching Plant is that it can also be used for outloading of bunkers and storages, and loading of containers.

    Concreting is expensive; the Mobile Batching Plant will save a considerable sum of money in term of costs to have pre-made concrete delivered.

  • Specifications

    Capacity of hopper 8 cubic metres, 14t

    Capacity of concrete per hour 30 cubic metres

    Empty weight 3.95t

    Petrol engine 27hp vanguard OR diesel 33hp Kubota

    Loading edge 2.7m deep

    Tipping edge height 3m

    Rear discharge conveyer 9m x 600mm

    Discharge height adjustable from 1.8 - 3.4m

    Something missing? Or want something different? Talk to us!

  • Features

    Full hydraulic operation of conveyor, hopper metering door, and stabilizer legs

    Load cells 4 x 5t Kelbra shearbeam loadcell 20t capacity

    Rinstrum R5100 indicator and high vis display

    Full protective guarding around hopper base and conveyor return

    High flow petrol and water pumps with outlet on conveyor discharge

    Retractable washdown hose

    Something missing? Or want something different? Talk to us!

  • Service post-delivery

    We pride ourselves on our complete service.

    If a problem arises, we will work with you to get your Mobile Batching Plant up and running as soon as possible.

  • Where can I get more info?

    Go to the Gallery for photos.

    Download a brochure.

    Contact Lee at Tecfitmac.

Brochure
